TP-Link RE305 AC1200 Wi-Fi Range Extender WIRELESS Working Modes Range Extender/Access Point HARDWARE FEATURES Plug Type EU, UK, US Interface 1 x 10/100Mbps Ethernet Port (RJ45) Button WPS Button, Reset Button Input Power 100-240V~50/60Hz Max. Power Consumption 7.3W（max power consumption） Dimensions ( W x D x H ) 3.1 x 3.0 x 3.0 in. (80 x 78 x 77mm) Antenna 2 External Antennas WIRELESS FEATURES Wireless Standards IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz Frequency 2.4GHz and 5GHz Signal Rate 300Mbps at 2.4GHz, 867Mbps at 5GHz Reception Sensitivity 5GHz： 11a 6Mbps:-91dBm 11a 54Mbps: -74dBm 11ac HT20 mcs8: -68dBm 11ac HT40 mcs9: -63dBm 11ac HT80 mcs9: -59dBm2.4GHz 11g 54Mbps: -79dBm 11n HT20 mcs7: -77dBm 11n HT40 mcs7: -74dBm Wireless Functions Enable/Disable Wireless Radio DFS (the latest firmware and hardware version is required) Access Control LED Control Power Schedule Wi-Fi Coverage Wireless Security 64/128-bit WEP WPA-PSK / WPA2-PSK Transmission Power 2.4G<17dBm， 5G<17dBm OTHERS Certification CE, FCC, RoHS Package Content AC1200 Wi-Fi Range Extender RE305 Quick Installation Guide Box Dimensions (W X D X H) 6.15 x 4 x 3.7 in. (156.5 x 101.5 x 95mm) System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux. Environment Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing For additional version information, please go to the support page. * Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specifications. Range and coverage specifications along with the number of connected devices were defined according to test results under normal usage conditions. Actual wireless transmission rate, wireless coverage, and number of connected devices are not guaranteed, and will vary as a result of 1) environmental factors, including building materials, physical objects and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead and 3) client limitations, including rated performance, location, connection quality, and client condition. **The product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or is non-standard or outdated. Actual network speed may be limited by the rate of the product’s Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions. �� Follow Us on Facebook Stay connected with our latest updates, deals, and promotions:�� Follow UniShop on Facebook for the latest offers and product insights. For router backup, order mini ups from here Please join UNISHOP customer community
